Elbows
Elbows.
14” high, up to 90° inclination capacity. Made in 0.020” thick MicroSilver aluminum, 98% reflective, resistant to moisture and humidity, corrosion and extreme weather.
We present to you our different lighting models.
(100 Watts light bulbs)
(100 Watts light bulbs)
(100 Watts light bulbs)
(100 Watts light bulbs)
(100 Watts light bulbs)
100% High impact acrylic, 0.220” thick, with UV stabilizer and CC2 light-transmitter plastic material.
100% anti-corrosive aluminum, 0.080” thick single-piece (2.032mm). Two flashing options:
Flat: 4”, 6” or 8” high
Tilt: for 3-5/12 tilt roofs
It can be adapted for roofs with higher tilt by using elbows.
Polypropylene adhesive tape that prevents dust, dirt, air and insects from entering.
0.020” thick MicroSilver reflective aluminum, resistant to corrosion, humidity and extreme weather.
High-impact prismatic, 0.125” thick (3 layers), UV stabilizer and CC1 light-transmitter plastic material.
0.080” thick aluminum ring. Used to hold the diffuser in its place.
14” high, up to 90° inclination capacity. Made in 0.020” thick MicroSilver aluminum, 98% reflective, resistant to moisture and humidity, corrosion and extreme weather.
Helps to control light levels. It can reduce light intensity up to a 98%. Equipped with remote control.
0.020” thick MicroSilver aluminum, 98% reflective, resistant to moisture and humidity, corrosion and extreme weather.
Extracts odors and cleanses the environment. 110 ft3 per minute capacity.
Provides night lighting. A light bulb is fixed to the inside of the tube by means of a small
The light unit works the same way a regular light bulb works.Sustainable solutions
| Motor | Area to cover | Extraction |
|---|---|---|
| 10 watts | 1,200 ft2 - 110m2 | 850 ft2 - 20m2 |
| 20 watts | 2,000 ft2 - 185m2 | 1,100 ft2 - 30m2 |
| 30 watts | 2,500 ft2 - 230m2 | 1,500 ft2 - 40m2 |
SOLUX fans are designed to allow efficient air circulation inside the area where the system is installed.
SOLUX can provide you two different kinds of fans, Attic Fans and Gable Fans. Both fans work with solar energy captured by solar cell panels.
SOLUX can equip both fans with 10, 20 and 30 Watts engines, so that areas of different sizes can all be properly ventilated
